Features
| Technical Specification | |
| Maximum Scanning Depth | max. 250mm |
| Multi-frequency | 5 segment frequencies |
| Scanning mode | B, 2B, B/M, M, 4B, 9B, ZOOM |
| Real-time Zoom on B mode | |
| Image gray scale | 256 level gray scale |
| Image processing | Pre-processing, after-processing, dynamic range, frame rate, line average, edge; enhancement, Black/White inversion; Gray scale adjustment, contrast, brightness, γ revision |
| Gain | 0-100dB |
| Time gain control(TGC) | 8 segment adjustment, B, M adjustment separately |
| Measurement and calculation | |
| B mode | distance, circumstance, area, volume, angle, ratio, stenosis, profile, histogram |
| M mode | heart rate, time, distance, slope and stenosis |
| Gynecology measurement | Uterus, cervix, endometrium, L/R ovary |
| Obstetric | gestation age, fetal weight, AFI |
| Cardiology | LV, LV function, LVPW, RVAWT |
| Urology | transition zone volume, bladder volume, RUV, prostate, kidney |
| Small parts | optic, thyroid, jaw and face |
| Veterinary software(optional) | Cattle: BPD, CRL, TD; Horse: GA; Dog: GS; Cat: HD, BD; Sheep: BPD, CRL, TD |
| Others | |
| Supported output apparatus | U-Disk, Laser/ink printer, video printer, VGA |
| Zoom | 10 ratio, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0 |
| Image store | by hardisk or USB disk |
| 3D image function(function) | can get rebuilt 3D image, Optional |
| Work time by built-in battery | about 5 hours |
| Monitor | 15 inch color LED screen |
| Probe Connector | 2 |
| Dimension | 362mm×340mm×60mm |
| Weight | Around 4.8Kg |
Wuxi Biomedical Technology is a professional manufacturer of infrared vein finder, digital otoscope, ultrasound scanner, color doppler and digital electronic colposcope. Now we are trying to expand product field to ECG, Patient Monitor, Oxygen Concentrator and infusion pump and so on.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in medical field.
Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. Because we have own R&D capabilities to develop innovative medical devices. Sophisticated management and assessment ensure good reputation and quality.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success! We are trying our best to offer professional after-sale service and promise you buying with satisfaction, using at ease.
Transport
1. Shipment will be arranged as 7working days after getting the payment.
2. Import fees and charges are the buyer's responsibility.
To make sure that you may receive the items at the minimum tax, we will negotiate the name of the item with low value.
If you have special requests, please advise us on your order advance.
1. For all your inquires, we will reply you in detail within 24 hours
2. We own professional team who have professional attitude to recommend products and services, introducing for you.
3. The product has one year free warranty, after it is still providing after-sales service;
4. We offer OEM services. Can print your own logo on the product;
5. We have very experienced engineers; can help you better use our products.
Your satisfaction is our duty! It will be our great honor to serve you.
We do hope we can offer you more help in medical field and build the long term business relationship with you.
Q: How to buy your products?
A: For some products we have on stock , you can take away the products after you arrange the payment ;
If we don't have stock ,we will start the production once getting the payment .
Q: What's the warranty for the products?
A: The free warranty is one year from the date of exportation date.
Q: Can we visit your factory?
A: Of course, welcome to visit our factory if you come to China.
Q: How long is the validity of quotation?
A: Generally, our price is valid within one month from the date of quotation.
The price will be adjusted appropriately as the price fluctuation of raw material in the market.
Q: What's the production date after we confirm the order?
A: This depends on the quantity. Normally, it is about 3-7 working days at sight of your payment. Please contact us for more detail information.
