Hood | ||||||||
Tubing access ports | 10 | |||||||
Access door size | 18cm x 13cm | |||||||
Mattress to hood height | 48.0mm | |||||||
Soft bed mattress size | 73.6cm x38.6cm x1.8cm | |||||||
Temperature control modes: Skin and air temperature control mode | ||||||||
Air mode control temperature range | 20ºC-37ºC | |||||||
Air mode control override temperature range | 37ºC-39ºC | |||||||
Air mode control accuracy | ≤±1.0ºC | |||||||
Skin mode control temperature range | 34ºC-37ºC | |||||||
Skin mode control override temperature range | 37ºC-38ºC | |||||||
Skin temperature accuracy | ±0.3ºC | |||||||
Dual-skin temperature monitoring | Yes | |||||||
Servo Humidity | ||||||||
Humidity control range | 30%-95% RH | |||||||
Humidity control operating time without refilling | 24 hours | |||||||
Humidity control reservoir capacity | 1500ml | |||||||
Humidity display accuracy | ±5%RH | |||||||
Humidity control accuracy | ±5% RH | |||||||
Servo Oxygen (Optional) | ||||||||
Oxygen control range | 21 % to 65% | |||||||
Oxygen display accuracy of full scale | ±2% | |||||||
Oxygen control accuracy (100% calibration) | ±3% | |||||||
Oxygen control accuracy (21% calibration) | ±5% | |||||||
Oxygen display resolution | 1% | |||||||
Scale (Optional) | ||||||||
Weight range | 300g to 8kg | |||||||
Weight display resolution | 1g | |||||||
Weight accuracy | ±10g | |||||||
Operating Environment | 20ºC to 30ºC | |||||||
Humidity | 10 to 95% RH | |||||||
Air Velocity | Up to 0.3m/sec |
